Chapter 5: Local Management
5-14 2H28-08R SmartSwitch 2208 User’s Guide
DEVICE STATISTICS
The Device Statistics screen provides statistics and performance
information for the 2H28-08R. For details, refer to
Section 5.17 .
NETWORK TOOLS
The Network Tools function resides on the 2H28-08R and consists of a
series of commands that allow the user to access and manage network
devices. For details, refer to
Section 5.21 .
5.6 DEVICE CONFIGURATION MENU SCREEN
The Device Configuration Menu screen, Figure 5-8 , provides access to
Local Management screens. These screens allow the user to configure and
monitor operating parameters, modify SNMP community names, set
SNMP traps, configure switch parameters and configure 2H28-08R ports.
To access the Device Configuration Menu screen from the Device Menu
screen, use the arrow keys to highlight the DEVICE
CONFIGURATION menu item and press ENTER. The Device
Configuration Menu screen displays.
NOTE
The following menu items on the Device Configuration Menu
screen may not display if the operational mode of the module
has been set to SECURE FAST VLAN:
SWITCH CONFIGURATION
SMARTTRUNK CONFIGURATION
Refer to the Release Notes to see if the functionality provided
by the above screens is supported in SECURE FAST VLAN
mode.
Section 5.7.9 provides instructions on setting the operational
mode.
