Chapter 4: Troubleshooting
4-2 2H28-08R SmartSwitch 2208 User’s Guide
NOTE
The terms flashing, blinking, and solid used in Table 4-1
indicate the following:
Flashing indicates an LED pulse that is flashing at a random
rate.
Blinking indicates an LED pulse flashing at a steady rate
(50% on, 50% off).
Solid indicates a steady LED light. No pulsing.
Table 4-1 LANVIEW LEDs
LED Color State Recommended Action
PWR Green Solid. Functional.
Power supply(ies)
operating normally. None.
Amber Solid. Indicates loss of
power supply
redundancy. 1. Ensure that the power cords
are plugged in correctly and
that there is power at the
power source.
2. Contact the Cabletron
Systems Global Call Center
if problem still exists.
CPU Off Power off. Power up device.
Red Blinking. Hardware
failure has occurred. Contact the Cabletron
Systems Global Call Center.
Solid. Resetting,
normal power up reset. None.
Amber Blinking. Crippled. Contact the Cabletron
Systems Global Call Center.
Solid. Testing. None.
Green Solid. Functional. None.
Amber
and
Green Blinking amber and
green while booting. None.
