Chapter 5: Local Management
5-60 2H28-08R SmartSwitch 2208 User’s Guide
5.17 DEVICE STATISTICS MENU SCREEN
The Device Statistics Menu screen, Figure 5-23 , provides access to
screens that allow the user to obtain switch statistics about frame traffic
through each port, to view MIB-II statistics from each port, and to view
RMON Statistics gathered by the RMON agent embedded in the
2H28-08R.
To access the Device Statistics Menu from the Device Menu screen, use
the arrow keys to highlight the DEVICE STATISTICS menu item and
press ENTER. The Device Statistics Menu
screen displays.
Figure 5-23 Device Statistics Menu Screen
NOTE
The following menu item on the Device Statistics Menu screen
will not display if the operational mode of the device has been
set to SECURE FAST VLAN:
SWITCH STATISTICS
Section 5.7.9 provides instructions on setting the operational
mode.
Firmware Revision: XX.XX.XX
Device Statistics Menu
SWITCH STATISTICS
INTERFACE STATISTICS
RMON STATISTICS
2286-67
Device Type: 2H28-08R
BOOTPROM Revision: XX.XX.XX
2H28-08R LOCAL MANAGEMENT
EXIT RETURN
