Installing System Components
81
Power Supplies
Your system supports two 1100 W power supplies.
NOTE:
The power supply label specifies the maximum power output.
If only one power supply is installed, it must be installed in the first power
supply bay.
CAUTION:
To ensure proper system cooling, the power supply blank must be
installed in the second bay in a non-redundant configuration. See "Installing a
Power Supply Blank" on page 83.
1 system cover 2 cooling shroud
3 PCIe expansion card slots (6) 4 cooling fan modules (4)
5 heat sink blank (single-processor
configuration) 6 memory modules (up to 18 total, 9 for
each processor)
7 system feet (4) 8 heat sink and processor (1 or 2)
9 SAS or SATA hard drives (up to 8
[3.5"] and 16 [2.5"]) 10 control panel
11 tape drive (optional) 12 optical drive
13 internal SD module (optional) 14 SAS backplane
15 RAID battery (optional) 16 chassis intrusion switch
17 integrated storage controller card
