Installing System Components
127
RAID Battery
Removing a RAID Battery
WARNING:
Only trained service technicians are authorized to remove the system
cover and access any of the components inside the system. Before you begin this
procedure, review the safety instructions that came with the system.
1 Turn off the system and attached peripherals, and disconnect the system
from the electrical outlet and peripherals.
2 Rotate the system feet inward and lay the system on a flat surface.
3 Open the system. See "Opening the System" on page 85.
4 Disconnect the RAID battery cable from the connector on the integrated
storage card.
Press the tab on the RAID battery cable connector, and gently pull the
cable connector out of the connector on the storage card. See Figure 3-21.
5 Pull the battery carrier release tab, and pull the battery carrier upwards and
out of the battery carrier slots on the chassis. See Figure 3-21.
6 Pull back gently on the two tabs holding the RAID battery in the battery
carrier and draw out the RAID battery from the battery carrier. See
Figure 3-21.
