Dell PowerEdge T710 User Manual
Page 133
Installing System Components
133
Figure 3-23.
Removing and Installing an Integrated Storage Controller Card
1
data cables
2
integrated storage controller card
cable connectors
3
integrated storage controller card
4
card guides (2)
5
integrated storage controller card
slot
1
2
3
4
5
book.book Page 133 Monday, June 15, 2009 11:33 AM
