Dell PowerEdge T710 User Manual
Page 157
Installing System Components
157
Figure 3-31.
Removing and Installing the Power Distribution Board
1
power distribution board plate
2
power distribution plate screws (2)
3
power distribution board
4
power distribution board cables (6)
5
securing tabs
6
power distribution board screws (5)
1
2
3
4
6
5
book.book Page 157 Monday, June 15, 2009 11:33 AM
