126
Installing System Components
Figure 3-20. Removing and Installing a NIC Hardware Key
7 Install the integrated storage controller card. See "Installing an Integrated
Storage Controller Card" on page 134.
8 Close the system. See "Closing the System" on page 86.
9 Place the system upright and on its feet on a flat, stable surface.
10 Rotate the system feet outward.
11 Reattach any peripherals, then connect the system to the electrical outlet.
12 Turn on the system and attached peripherals.
1 NIC hardware key 2 ISCSI_KEY connector
2
1
