Ethernet*

Ethernet
Settings

Auto

Detects Ethernet transmission rate and the duplex settings
automatically.

10Base-T
Half-Duplex

Selects 10Base-T Half-Duplex as the default value.

10Base-T
Full-Duplex

Selects 10Base-T Full-Duplex as the default value.

100Base-TX
Half-Duplex

Selects 100Base-T Half-Duplex as the default value.

100Base-TX
Full-Duplex

Selects 100Base-T Full-Duplex as the default value.

Current Ethernet Settings

Displays the current settings of Ethernet.

MAC Address

Displays the printer's MAC address.

Port
Settings

LPD

Select the check box to enable the LPD.

Port9100

Select the check box to enable the Port9100.

IPP*

Select the check box to enable the IPP port.

WSD

Select the check box to enable the WSD port.

FTP

Select the check box to enable the FTP port.

SMB*

Select the check box to enable the SMB.
You can also configure the transport protocol to be used.
TCP/IP and NetBEUI can be selected simultaneously as the
transport protocol.

NetWare*

Select the check box to enable the NetWare port. You can also
configure the transport protocol to be used. IPX/SPX and
TCP/IP can be selected simultaneously as the transport
protocol.

AppleTalk*

Select the check box to enable the AppleTalk port.

Bonjour (mDNS)*

Select the check box to enable the Bonjour (mDNS) feature.

E-Mail Alert

Select the check box to enable the E-Mail Alert feature.

SNMP Agent

Select the check box to enable the SNMP.
You can also configure the transport protocol to be used. UDP
and IPX can be selected simultaneously as the transport
protocol.
IPX is only available when the multi protocol card is installed.

The Ethernet settings are not displayed when the optional wireless printer adapter is installed.

An optional multi protocol card is required to display these items.
