Installing System Components
165
Removing the Control Panel Board
CAUTION:
Many repairs may only be done by a certified service technician.
You should only perform troubleshooting and simple repairs as authorized in
your product documentation, or as directed by the online or telephone service
and support team. Damage due to servicing that is not authorized by Dell is not
covered by your warranty. Read and follow the safety instructions that came
with the product.
1 Turn off the system and attached peripherals, and disconnect the system
from the electrical outlet.
2 Open the system. See "Opening the System" on page 89.
3 If applicable, remove the memory-riser blanks. See "Removing a Memory-
4 Remove the memory risers. See "Removing a Memory Riser" on page 100.
5 Remove the memory-riser guide. See "Removing the Memory-Riser Guide"
6 Disconnect the cables connected to the control panel board.
NOTE:
Note the routing of the cables on the side on the system as you remove
them from the control panel board. You must route these cables properly
when you replace them to prevent them from being pinched or crimped.
7 Using a T10 Torx driver, remove the three screws that secure the control
panel board to the chassis. See Figure 3-35.
8 Using a T8 Torx driver, remove the screw that secures the control panel
board on the front of the system. See Figure 3-35.
9 Slide the control panel assembly toward the back of the system and take
it out.
