108 Installing System Components
Removing a Hard-Drive Blank
CAUTION: To maintain proper system cooling, all empty hard-drive bays must
have drive blanks installed.
1 Turn off the system, including any attached peripherals, and disconnect
the system from its electrical outlet.
2 If installed, remove the front bezel. See "Removing the Front Bezel" on
page 87.
3 Press the release tab and slide the drive blank out until it is free of the drive
bay. See Figure 3-11.
Figure 3-11. Removing or Installing a Hard-Drive Blank
Installing a Hard-Drive Blank
1 If installed, remove the front bezel. See "Removing the Front Bezel" on
page 87.
2 Insert the drive blank into the drive bay until the blue release tab clicks
into place.
3 If applicable, install the front bezel. See "Installing the Front Bezel" on
page 87.
1 hard-drive blank 2 release tab
1
2
