The agsstate screen displays a numeric value
corresponding to why the generator is or is not
running. This is a diagnostic feature for OutBack
troubleshooting purposes. Press the
soft key to view the next TIMER screen.
AGS state can be one or more of the following
numbers:
Manual Start 128
Exercise 64
Time of Day 32
Load Start 16
Voltage 24hr/2hr 8
Voltage 2min 4
SOC Start 2
An AGS state of 128 means that AGS is active
because of a manual start. More then one reason
can be true at any one time (e.g., AGS state of 20
would be load start and 2 min voltage timer). The
generator will be running any time AGS state is
greater then 0.
The agsgenfault screen displays three states:
• 0 or no generator fault
• 1 indicates the generator did not start and there
is no AC input after five minutes
• 2 indicates the generator started, but then
stopped (e.g., it ran out of fuel)
Press the soft key to proceed.
The 24 hr vs time screen counts down the minutes,
starting at 1440, of the 24-hour voltage start set
point. After the battery voltage has fallen below its
24-hour set point, the timer starts and is displayed
here. Pressing the soft key brings up
the 2hr vs time screen.
The 2hr vs time 120 min screen counts down
the 2-hour voltage start set point. Pressing the
soft key leads to the 2 min vs time
screen.
The 2 min vs time screen counts down the
2-minute voltage start set point. Pressing the
soft key leads to the lsstart timer
screen.
ADV/MATE/AGS/TIMERS------------
agsstate 0
DOWN AGS
ADV/MATE/AGS/TIMERS ----------
agsgenfault 0
DOWN UP
ADV/MATE/AGS/TIMERS---------
24 hr 1440 min
vs time
DOWN UP
ADV/MATE/AGS/TIMERS---------
2hr vs time 120 min
DOWN UP
ADV/MATE/AGS/TIMERS ---------
2 min 2 min
vs time
DOWN UP
ADV/MATE/AGS/PG3---------------
choose category
%SOC
PG2 START TIMERS PG4
Press the <TIMERS> soft key to view the
various AGS timer-related screens.
