ADV/MATE/AGS/SETUP---
ags fault 17 min
time
DOWN UP INC DEC
QUIET TIME
MATE/AGS/SETUP------
end of AGS SETUP
menu
UP TOP AGS
MAIN----------------
6:54:42P
SUM STATUS SETUP ADV
ADV/SETTINGS/WARNING
changes made could
adversely effect
system performance
ADV/PASSWORD--------
enter the password:
132
ENTER INC DEC EXIT
ADV/MATE/PG1
choose category:
HBX GRIDUSE AGS PG2
ADV-----------------
choose device:
FX CC DC MATE
ADV/MATE/AGS/QT-----
weekday: 12:00A
quiet time start
DOWN AGS CHANGE
ADV/MATE/AGS/QT-----
weekday: 12:00A
quiet time stop
DOWN UP CHANGE
ADV/MATE/AGS/QT-----
weekend: 12:00A
quiet time start
DOWN UP CHANGE
ADV/MATE/AGS/QT-----
weekend: 12:00A
quiet time stop
DOWN UP CHANGE
MATE/AGS/QT---------
end of QUIET TIME
menu
UP TOP AGS
VOLTAGE START
MAIN----------------
6:54:42P
SUM STATUS SETUP ADV
ADV/SETTINGS/WARNING
changes made could
adversely effect
system performance
ADV-----------------
choose device:
FX CC DC MATE
ADV/MATE/PG1
choose category:
HBX GRIDUSE AGS PG2
ADV/MATE/AGS--------
Choose category:
QUIET VOLT
SETUP TIME START PG2
ADV/MATE/AGS/VSTART-
volt start 24.4 vdc
24 hr setting
DOWN AGS INC DEC
ADV/MATE/AGS/VSTART-
volt start 23.6 vdc
2 hr setting
DOWN AGS INC DEC
AGS/MATE/AGS/VSTART-
volt start 22.0 vdc
2 min setting
DOWN AGS INC DEC
ADV/MATE/AGS/VSTART-
end of VOLTAGE
START menu
UP TOP AGS
LOAD START
MAIN----------------
6:54:42P
SUM STATUS SETUP ADV
ADV/SETTINGS/WARNING
changes made could
adversely effect
system performance
ADV/PASSWORD--------
enter the password:
132
ENTER INC DEC EXIT
ADV-----------------
choose device:
FX CC DC MATE
ADV/MATE/PG1
choose category:
HBX GRIDUSE AGS PG2
ADV/MATE/AGS--------
Choose category:
QUIET VOLT
SETUP TIME START PG2
ADV/MATE/AGS/PG2----
Choose category:
LOAD MUST
PG1 START RUN PG3
ADV/MATE/AGS/LS-----
load start 0 kw
DOWN AGS INC DEC
ADV/MATE/AGS/LS-----
load start 1 min
delay
DOWN UP INC DEC
ADV/MATE/AGS/LS-----
load stop 0 kw
DOWN UP INC DEC
ADV/MATE/AGS/SETUP---
cool down time 0
minutes
DOWN UP INC DEC
ADV/MATE/AGS/SETUP---
wrm up time 0
minutes
DOWN UP INC DEC
ADV/PASSWORD--------
enter the password:
132
ENTER INC DEC EXIT
ADV/MATE/AGS--------
Choose category:
QUIET VOLT
SETUP TIME START PG2
