INVERTER CONTROL
currently: ON
OFF SRCH ON OK
AC IN HOT KEY
AC INPUT CONTROL
currently: DROP
DROP USE OK
GEN START CONTROL
currently: MAN-OFF
OFF AUTO ON OK
CHARGER CONTROL
currently: OFF
OFF AUTO ON OK
CHARGER MODE CONTROL
global charger mode
BULK EQ OK
INV HOT KEY
SUMMARY SCREENS
MAIN----------------
6:54:42P
SUM STATUS SETUP ADV
CC TOTALS 14.5 V
Output 0A 0.000kW
Today 0.0kWH
MODES
MAIN----------------
6:54:42PM
SUM STATUS SETUP ADV
STATUS--------------
choose device:
FX CC DC MAIN
STATUS/FX/PAGE1-----
choose category:
MODES METER BATT PG2
STATUS/FX/MODE---P00
inv control: ON
CHANGE
DOWN STAT MODE PORT
FX Total 12.6V 97%
Inverting 0.000kW
AC Loads 0.000kW
Buying $ 0.000kW
INVERTER CONTROL P00
currently: ON
OFF SRCH ON OK
STATUS/FX/MODE---P00
inv control: ON
CHANGE
DOWN STAT MODE PORT
AC INPUT CONTROL
currently: USE
DROP USE OK
STATUS/FX/MODE---P00
ac in control: USE
CHANGE
DOWN UP MODE PORT
STATUS/FX/MODE---P00
chr control: AUTO
CHANGE
DOWN UP MODE PORT
CHARGER CONTROL P00
currently: AUTO
OFF AUTO ON OK
STATUS/FX/MODE---P00
chr control: AUTO
CHANGE
DOWN UP MODE PORT
STATUS/FX/MODE---P00
aux control: AUTO
CHANGE
DOWN UP MODE PORT
STATUS/FX/MODE---P00
ac in control: USE
CHANGE
DOWN UP MODE PORT
AUX OUTPUT CONTROL
currently: AUTO
OFF AUTO ON OK
STATUS/FX/MODE---P00
aux control: AUTO
CHANGE
DOWN UP MODE PORT
EQUALIZE CONTROL
eq enabled: NO
START STOP EXIT
METERS
MAIN----------------
6:54:42PM
SUM STATUS SETUP ADV
STATUS--------------
choose device:
FX CC DC MAIN
STATUS/FX/PAGE1-----
choose category:
MODES METER BATT PG2
SILENT P00
inv 0.0kw zer 0.0kw
chg 0.0kw buy 0.0kw
DOWN STATUS PORT
STATUS/FX/MODE---P00
eq enabled:
CHANGE
UP MODE PORT
STATUS/FX/METER-—P00
output 122 vac
voltage
DOWN UP TOP PORT
STATUS/FX/METERS--P00
input 122 vac
voltage
DOWN UP TOP PORT
AC IN
INV
FIRST PRESS
SECOND PRESS
THIRD PRESS
FOURTH PRESS
MATE MENUS
