To debug the system, press the soft
key.
On the DEBUG screen, first press the
soft key to bring up a list of HUB ports with a
count of communications errors for each port;
allows you to reset the error counting
display (see next screen).
This is a typical VIEW screen showing the HUB
Ports and any communication errors in the
system. The numbered port with more than one
error will need correcting. After the errors are
corrected, all the used ports will return to 000
or 001 values after pushing the soft key.
Press any soft key to return to the SETUP/MATE/
COMM screen. To correct errors, please see “Er-
rors and Debugging” in the section that follows. If
no errors are present, pressing any soft key returns
to the previous SETUP/MATE/COMM screen.
Press the soft key to clear the error-
counting display. Press the soft key
to return to the “choose category” screen. Press
to return to the previous screen.
SETUP/MATE/COMM--------------
comm errors:
BACK VIEW RSET
00:000 01:000 02:000
03:000 04:025 05:001
06:001 07:001 08:001
09:001 10:001 2M:001
SETUP/MATE/COMM--------------
comm errors:
BACK VIEW RSET
SETUP/MATE/PAGE2--------------
choose category:
BACK REPOLL PC DEBUG
