Press the soft key to enable or disable the
MATE’s RS232 communications port.
In the PC communications screen, choose ON or
OFF by pressing the respective soft key. Press the
soft key to return to the choose category
screen.
Press the soft key after a device is
added to, moved, or removed from the HUB.
The MATE has found the HUB and will automati-
cally go to the Port Assignment screen.
After displaying the devices connected to each
Port, the MATE returns to the choose category
screen on its own.
SETUP/MATE/PAGE2--------------
PC communications: OFF
BACK OFF ON
SETUP/MATE/PAGE2--------------
choose category:
BACK REPOLL PC DEBUG
SETUP/MATE/PAGE2--------------
choose category:
BACK REPOLL PC DEBUG
Searching for Devices
HUB Found
Port Assignment
1> FX 2> FX 3> CC 4> CC
5> 6> 7> 8>
9> 10> 2M>
NOTE: Disconnecting the MATE’s CAT5 cable and then reconnecting it also performs the
re-poll task, but the cable can be inconvenient to remove from a mounted MATE.
