2. Open the system. See Opening the System .
3. Locate the memory module sockets. See System Board Connectors .
4. Press down and out on the ejectors on each end of the socket until the memory module pops out of the socket. See Figure 3 -21 .
5. Close the system. See Closing the System .
6. Stand the system upright.
Microprocessor
You can upgrade the system processor to take advantage of future options in speed and functionality.
A processor upgrade kit contains the following items:
l Processor
l Thermal grease packet and/or a replacement heat sink
If your kit does not include a replacement heat sink, you must reuse the processor heat sink currently in your system.
Removing the Processor
1. Turn off the system, including any attached peripherals, and disconnect the system from the electrical outlet.
2. Open the system. See Opening the System .
3. Remove the cooling shroud. See Removing the Cooling Shroud .
4. Remove the heat sink. See Figure 3 -22 .
a. Open one securing clip by pressing the end of the clip down and away from the retention module until it clears the securing tab on the retention
module, and then lift the clip up.
b. Repeat step a for the remaining securing clip.
c. Rotate the heat sink slightly and then lift the heat sink off the processor. Do not pry the processor off the heat sink.
d. If you are reusing the heat sink with the new processor, clean the contact side of the heat sink and set it aside for use later in the processor
installation procedure.
Figure 3-22. Removing the Heat Sink
NOTICE: If your upgrade kit included a thermal grease packet, you must use the thermal grease as instructed to ensure the proper thermal operating
condition for the processor. Failure to do so will result in damage to your system.
CAUTION: Only trained service technicians are authorized to remove the system cover and access any of the components inside the system.
Before performing any procedure, see your Product Information Guide for complete information about safety precautions, working inside the
computer, and protecting against electrostatic discharge.
NOTICE: Never remove the heat sink from a processor unless you intend to remove the processor. The heat sink is necessary to maintain proper
thermal conditions.
