64 Using the System Setup Program and UEFI Boot Manager
Integrated Devices Screen
Option Description
Integrated SAS
Controller
(Enabled default)
Enables or disables the integrated storage controller.
User Accessible USB
Ports
(All Ports On default)
Enables or disables the user-accessible USB ports. Options
are All Ports On, Only Back Ports On, and All Ports Off.
Internal USB Port 1
(On default)
Enables or disables the internal USB port.
Internal USB Port 2
(On default)
Enables or disables the internal USB port.
Embedded NIC1 and
NIC2
(Enabled default)
Enables or disables the operating system interface of the
two embedded NICs. (The NICs may also be accessed
through the system’s management controller.)
Embedded Gb NICx
(NIC1 default: Enabled
with PXE;
Other NICs: Enabled)
Enables or disables the embedded NICs. Options are
Enabled, Enabled with PXE, and Enabled with iSCSI
Boot. PXE support allows the system to boot from the
network.
MAC Address Displays the MAC address for the NIC.
OS Watchdog Timer
(Disabled default)
Sets a timer to monitor the operating system for activity,
and aids in recovery if the system stops responding.
When Enabled, the operating system is allowed
to initialize the timer. When Disabled, the timer is
not initialized.
NOTE: This feature is usable only with operating systems
that support WDAT implementations of the Advanced
Configuration and Power Interface (ACPI) 3.0b specification.
Embedded Video
Controller
(Enabled default)
Displays the total amount of video memory available in
the embedded video controller.
