112

Installing System Components

Table 3-4. Expansion-Card Installation Priority for Riser 2

Table 3-3. Expansion-Card Installation Priority for Riser 1

Card
Priority

Card Type

Slot
Priority

Max
Allowed

25-W
Card

1

PERC S300*

1, 2

2

Y

2

PERC H800

3, 2

2

Y

3

HPCC

2, 1

2

Y

4

Fibre Channel

2, 1

2

Y

5

10 Gb NIC

2, 1

2

Y

6

All other NICs

1, 2

2

N

7

All other Dell internal

storage cards

4

1

Y

8

Non-Dell storage cards

1, 2

2

N*

*

PERC S300 is available only on eight–hard-drive systems.

Card
Priority

Card Type

Slot
Priority

Max
Allowed

25-W
Card

1

PERC H700

2

1

Y

2

PERC H200

2

1

Y

3

All other NICs

1

1

N

4

Non-Dell storage cards

1

1

N
