Installing System Components 139
Installing the Control-Panel Module–LED
CAUTION: Many repairs may only be done by a certified service technician.
You should only perform troubleshooting and simple repairs as authorized in
your product documentation, or as directed by the online or telephone service
and support team. Damage due to servicing that is not authorized by Dell is not
covered by your warranty. Read and follow the safety instructions that came
with the product.
1 Assemble the power button and power button board in the control-panel
module.
2 Tighten the screw to secure the power button board to the control-panel
module. See Figure 3-27.
3 Connect the control-panel cable to the control-panel module.
4 Replace the bracket and tighten the single screw to secure the bracket to
the back of the control-panel module.
5 Reconnect the system to the power source and turn on the system and
attached peripherals.
6 If applicable, replace the front bezel. See "Installing the Front Bezel" on
page 83.
