Setting Up and Using Your Tablet-PC 81
Installing the Main Battery
1 If the Tablet-PC is connected to a docking device such as the optional
media base or battery slice (docked), undock it. See "Undocking Your
Tablet-PC From the Media Base" on page 212 or "Undocking Your
Tablet-PC From the Battery Slice" on page 220.
2 Turn the Tablet-PC upside-down.
3 Align the battery with the battery bay sides, then slide the battery into the
bay and ensure that the two latch releases engage.
Storing a Battery
Remove the battery when you store your Tablet-PC for an extended period of
time. A battery discharges during prolonged storage. After a long storage
period, recharge the battery fully (see "Charging the Main Battery" on
page 79) before you use it.
1 battery release latches (2) 2 battery
1 2
