Media Base (Optional) 204
Right View
USB C O N N E C TO R
T A B L E T -PC RE LE A SE L E VE R — Releases the Tablet-PC from the media base if the
media base is not secured by an antitheft device.
SE C U R I T Y CA BLE S L O T — Lets you attach a commercially available antitheft device
to the media base. Instructions for installing antitheft devices are usually included
with the device. For more information, see "Securing the Media Base" on page 210.
Back View
1 USB connector 2 Tablet-PC release lever
3 security cable slot
The USB 2.0-compliant connector allows you to connect
USB devices, such as a mouse, keyboard, or printer.
1 2 3
1 2 3 4 5 6 9 7 10 8
