Adding and Replacing Parts

2 Align the card with the connector at a 45-degree angle, and press the card

into the connector until it clicks.

NOTE:

For more specific information about which cable to connect to which

connector, see the documentation that came with your Mini-Card.

3 Connect the cables to the Mini-Card, ensuring that you route the cables

correctly.

4 Replace the memory and Mini-Card cover, and tighten the two captive

Hinge Cover

CAUTION:

Before you begin any of the procedures in this section, follow the

safety instructions in the

Product Information Guide.

NOTICE:

To avoid electrostatic discharge, ground yourself by using a wrist

grounding strap or by periodically touching an unpainted metal surface (such as a

connector on the back of the Tablet-PC).

NOTICE:

The hinge cover is fragile and can be damaged if extreme force is used.

Be careful when removing the hinge cover.

Removing the Hinge Cover

1 Follow the procedures in "Before You Begin" on page 155.
2 Turn the Tablet-PC top-side up, and then open the display all the way (180

degrees) so that the display rests on your work surface.

NOTICE:

To avoid damaging the hinge cover, do not lift the cover on both sides

simultaneously. Removing the hinge cover in a different way than described may

cause the plastic to break.
