Removing and Installing Parts
www
.dell.com | support.dell.com
9 PCI sound card with
IEEE 1394 • Line-in connector — Use the blue line-in connector to attach a record/playback
device such as a cassette player, CD player, or VCR.
• Microphone connector — Use the pink microphone connector to attach a
personal computer microphone for voice or musical input into a sound or
telephony program.
• Line-out connector — Use the green line-out connector to attach headphones and
most speakers with integrated amplifiers.
• Surround connector — Use the black surround connector to attach multichannel-
capable speakers.
• Center/LFE connector — Use the yellow center/Low-Frequency Effects (LFE)
connector to attach your subwoofer.
• IEEE 1394 connector — Attach high-speed serial multimedia devices, such as a
digital video camera.
NOTE:
For optimum performance, install a PCI sound card only in PCI slot 3 or 4.
10 modem connector If you have a modem, connect a telephone cable to the modem connector (optional).
NOTE:
For optimum performance, install a modem card only in PCI slot 2, 3, or 4.
11 DVI video connector If your monitor has a DVI connector, plug it into the DVI connector on the computer.
If your monitor has a VGA connector, plug it into the VGA connector on the
computer.
12 network adapter
connector To attach your computer to a network or broadband device, connect one end of a
network cable to either a network jack or to your network or broadband device.
Connect the other end of the network cable to the network adapter connector on the
back panel of your computer. A click indicates that the network cable has been
securely attached.
On computers with a network connector card, use the connector on the card.
It is recommended that you use Category 5 wiring and connectors for your network.
If you must use Category 3 wiring, force the network speed to 10 Mbps to ensure
reliable operation.
network or
broadband jack
