Appendix
107
Network adapter 10/100/1000 Ethernet connector
PS/2 (keyboard and mouse) 6-pin mini-DIN
USB two front-panel and six back-panel USB
2.0–compliant connectors
Audio one front-panel connector for
headphones; one front-panel connector
for microphone
System board connectors:
Primary IDE drive 40-pin connector
Secondary IDE drive 40-pin connector
Floppy drive 34-pin connector
Fans (3) 3-pin connector
I/O Panel 34-pin connector
Serial ATA (2) 7-pin connector
Sound Blaster
®
Audigy™ 2 sound card
connectors:
Audio five connectors for line-in, line-out,
microphone, surround, and center/Low-
Frequency Effects (LFE) channel
IEEE 1394 one front-panel 6-pin serial connector;
one back-panel 6-pin serial connector
Controls and Lights
Power control push button
Power light green light on power button—blinking
green in sleep state; solid green for power-
on state
Hard-drive access light green
Link integrity light (on integrated
network adapter) green light for 10-Mb operation; orange
light for 100-Mb operation; yellow light
for 1000-Mbps (or 1-Gbps) operation
Activity light (on integrated network
adapter) yellow blinking light
Diagnostic lights four lights on the back panel
Connectors (continued)
