Table 3 — 23XRV Dimensions (Marine Waterbox)
*Assumes both cooler and condenser nozzles on same end of chiller.
†1 or 3 pass length applies if cooler is a 1 or 3 pass design.
NOTES:
1. Service access should be provided per American Society of Heating, Refrigeration, and Air Conditioning Engineers
(ASHRAE) 15, latest edition, National Fire Protection Association (NFPA) 70, and local safety code.
2. Allow at least 3 ft (915 mm) overhead clearance for service rigging for frame R compressor.
3. Certified drawings available upon request.
4. Marine waterboxes may add 6 in. to the width of the machine. See certified drawings for details.
5. ‘A’ length and ‘B’ width dimensions shown are for standard 150 psi design and victaulic connections. The 300 psi design and/
or flanges will add length. See certified drawings.
Table 4 — 23XRV Waterbox Nozzle Sizes
Table 5 — 23XRV Compressor Weights
*Compressor weight is comprised of compressor, stator, rotor, and end bell.
Table 6 — 23XRV Component Weights — TR Compressor
*To determine compressor frame size, refer to Fig. 2.
HEAT EXCHANGER
SIZE
A (Length, Marine Waterbox — not shown) MAXIMUM
B WIDTH
MAXIMUM
C HEIGHT 2-Pass* 1 or 3 Pass†
ft-in. mm ft-in. mm ft-in. mm ft-in. mm
30 to 32 14- 9 4496 16-4 3 /
4
4997 6-9 3 /
8
2067 7-2 5 /
8
2200
35 to 37 16- 5 1 /
2
5017 18-1 1 /
4
5518 6-9 3 /
8
2067 7-2 5 /
8
2200
40 to 42 15- 2 3 /
4
4642 16-8 1 /
4
5086 6-9 3 /
4
2076 7-6 1 /
2
2299
45 to 47 16-11 1 /
4
5163 18-4 3 /
4
5607 6-9 3 /
4
2076 7-6 1 /
2
2299
50 to 52 15- 3 1 /
2
4661 16-8 1 /
2
5093 7-1 2159 7-6 3 /
4
2305
55 to 57 17- 0 5182 18-5 5613 7-1 2159 7-6 3 /
4
2305
FRAME
SIZE
PRESSURE
psig (kPa)
PASS
NOMINAL PIPE SIZE (in.) ACTUAL PIPE ID (in.)
Cooler Condenser Cooler Condenser
3
150/300
(1034/2068)
1 10 10 10.020 10.020
2 8 8 7.981 7.981
3 6 6 6.065 6.065
4
150/300
(1034/2068)
1 10 10 10.020 10.020
2 8 8 7.981 7.981
3 6 6 6.065 6.065
5
150/300
(1034/2068)
1 10 10 10.020 10.020
2 8 10 7.981 10.020
3 6 8 6.065 7.981
MOTOR
CODE
ENGLISH SI
Total Compressor
Weight*
(lb)
Total Compressor
Weight*
(kg)
P
4866 2207
Q
R
S
T
U
V
COMPONENT
FRAME 3
HEAT EXCHANGER*
FRAME 4
HEAT EXCHANGER*
FRAME 5
HEAT EXCHANGER*
lb kg lb kg lb kg
Suction Elbow 179 81 237 108 232 105
Discharge Pipe Assembly 747 339 747 339 747 339
Control Center 1650 749 1650 749 1650 749
Discharge Pipe Adapter Flange 178 81 178 81 178 81
Optional Isolation Valves 70 32 70 32 115 52
Optional Unit Mounted Pumpout Unit 164 75 164 75 164 75
Vaporizer Oil Sump 700 318 700 318 700 318
Economizer 542 246 542 246 542 246
