20
OIL SUPPLY
LINE
VAPORIZER
OIL PUMP
OIL FILTER
VAPORIZER HOT
GAS RETURN
LINE
OIL RECLAIM
LINE
OIL SUMP
OIL PRESSURE
REGULATOR ISOLATION
VALVE
OIL PRESSURE
REGULATOR VALVE
VAPORIZER HOT
GAS SUPPLY LINE
VAPORIZER
VENT LINE
BEARING OIL
DRAIN LINE
Fig. 25 — Oil Reclaim Piping
a23-1574
OIL SUMP
PRESSURE
SENSOR
OIL PUMP/OIL FILTER
ISOLATION VALVE
OIL FILTER
OIL PUMP
JUNCTION BOX
OIL PUMP/OIL FILTER
ISOLATION VALVE
OIL SUMP STRAINER
VAPORIZER REFRIGERANT
RETURN ORIFICE
OIL FILTER
SCHRADER
VALVE
OIL RECLAIM
ACTUATOR
OIL PRESSURE
LEAVING FILTER
SENSOR
OIL SUPPLY
LINE (TO
COMPRESSOR)
OIL PRESSURE
REGULATOR LINE
OIL RECLAIM
LINE ( FROM
COOLER)
OIL SUMP
TEMPERATURE
SENSOR
Fig. 26 — Oil Reclaim Components
a23-1575
