27
LEVEL GAGE
0' - 5 1/2"
[140mm]
PRESSURE GAGE
3/8" MALE FLARE
RELIEF VALVE CONN.
1/2" DIA. K.O.
ELECTRICAL CONN.
(PUMPOUT POWER)
1' - 7 "
[483mm]
0' - 5 7/8 "
[149mm]
(2) 1" NPT RELIEF
VALVE OUTLET (SEE FIELD
INSTALLATION NOTES)
0' - 9 "
[229mm]
TYPICAL
B
T
R
E
D
W
0'- 9 7/8"
[249mm]
1" NPT
LIQUID CONN.
0'- 9"
[229mm]
TYPICAL
VAPOR
3/4" NPT
PUMPOUT CONDENSER
WATER INLET CONN.
1/2" MALE FLARE
VAPOR CONN.
3/4" NPT
PUMPOUT CONDENSER
WATER OUTLET CONN.
ELECTRICAL SERVICE
ACCESS SPACE
20 3/4" X 8 3/4" X 4 1/2"
(BOTH SIDES)
V
U
N
A
G
M
J
K
L
F
1'-0 3/4"
[324mm]
3/8" MALE FLARE
RELIEF VALVE CONN.
1/2" DIA. K.O.
ELECTRICAL CONN.
(PUMPOUT POWER)
(FAR SIDE)
0'- 3 1/4"
[83mm]
0'- 10"
[254mm]
0'- 2 3/4"
[70mm]
0'- 7 15/16"
[202mm]
(FARSIDE)
C
P
S
H
DIMENSIONS
ENGLISH (ft-in.)
SI (mm)
TANK
SIZE
A
B
C
D
E
F
G
H
J
K
0428
10- 5
9-10
4-4
1
/
4
2-4
3
/
4
1-2
3
/
8
3-1
1
/
4
6
-4
3
/
16
3-11
3
/
8
3-4
7
/
8
2-9
9
/
16
0452
14-11
1
/
4
14- 4
1
/
2
4-8
1
/
4
2-8
1
/
2
1-4
1
/
4
3-4
1
/
2
7-2
1
/
4
4- 3
1
/
4
3-8
3
/
4
3-1
7
/
16
TANK
SIZE
L
M
N
P
R
S
T
U
V
W
0428
3-4
5
/
8
0-3
1
/
2
4- 9
1
/
2
1-7
7
/
8
2-0
3
/
8
3-9
5-0
1
/
4
2-5
2-9
7
/
8
2-5
3
/
4
0452
3-8
1
/
2
0-3
3
/
8
6-11
5
/
8
1-8
3
/
4
2-0
5
/
8
4-1
5-0
1
/
2
2-5
1
/
4
2-10
1
/
8
2-6
TANK
SIZE
A
B
C
D
E
F
G
H
J
K
0428
3175
2997
1327
730
365
946
1935
1203
1038
852
0452
4553
4381
1429
826
413
1029
2191
1302
1137
951
TANK
SIZE
L
M
N
P
R
S
T
U
V
W
0428
1032
89
1451
505
619
1143
1530
737
860
756
0452
1130
86
2124
527
625
1225
1537
742
867
762
NOTES:
1.
Denotes center of gravity.
2. Dimensions in [ ] are in
millimeters.
3. The weights and center of
gravity values given are for an
empty storage tank.
4. For additional information on
the pumpout unit, see certified
drawings.
5. Conduit knockout is located
on the side of the control box.
6. 28 cubic ft storage tank
weight: 2334 lb (1059 kg).
7. 52 cu ft storage tank weight:
3414 lb (1549 kg).
Fig. 38 — Optional Pumpout Unit and Storage Tank
TOP VIEW
LEFT SIDE VIEW
FRONT VIEW
a23-1541
a23-1542
a23-1543
