10
Table 7 — 23XRV Heat Exchanger Data
*Rigging weights are for standard tubes of standard wall thickness (Turbo-B3 and Spikefin 2, 0.025-in. [0.635 mm] wall).
NOTES:
1. Cooler includes the suction elbow and 1 /
2
the distribution piping weight.
2. Condenser includes float valve and sump, discharge stub-out, and 1 /
2
the distribution piping weight.
3. For special tubes refer to the 23XRV Computer Selection Program.
4. All weights for standard 2-pass NIH (nozzle-in-head) design with victaulic grooves.
Table 8A — 23XRV Additional Data for Cooler Marine Waterboxes*
*Add to heat exchanger data for total weights or volumes.
NOTES:
1. Weight adder shown is the same for cooler and condenser of equal frame size.
2. For the total weight of a vessel with a marine waterbox, add these values to the heat exchanger weights (or volume).
CODE
ENGLISH SI
Dry Rigging Weight
(lb)*
Machine Charge
Dry Rigging Weight
(kg)*
Machine Charge
Cooler
Only
Condenser
Only
Refrigerant
Weight (lb)
Liquid Weight
(lb) Cooler
Only
Condenser
Only
Refrigerant
Weight (kg) Liquid
Weight (kg)
With
Economizer
Without
Economizer
Cooler Condenser
With
Economizer
Without
Economizer
Cooler Condenser
30 4148 3617 800 650 464 464 1877 1676 363 295 210 210
31 4330 3818 800 650 531 542 1959 1769 363 295 241 246
32 4522 4023 800 650 601 621 2046 1860 363 295 273 282
35 4419 4529 910 760 511 513 2000 2089 413 345 232 233
36 4627 4758 910 760 587 602 2094 2195 413 345 266 273
37 4845 4992 910 760 667 692 2193 2299 413 345 303 314
40 5008 4962 900 750 863 915 2675 2746 408 340 391 415
41 5178 5155 900 750 930 995 2758 2839 408 340 422 451
42 5326 5347 900 750 990 1074 2832 2932 408 340 449 487
45 5463 5525 1015 865 938 998 2882 3001 460 392 425 453
46 5659 5747 1015 865 1014 1088 2976 3108 460 392 460 494
47 5830 5967 1015 865 1083 1179 3061 3214 460 392 491 535
50 5827 6013 1250 1100 1101 1225 3182 3304 567 499 499 556
51 6053 6206 1250 1100 1192 1304 3294 3397 567 499 541 591
52 6196 6387 1250 1100 1248 1379 3364 3485 567 499 566 626
55 6370 6708 1430 1280 1201 1339 3429 3620 649 581 545 607
56 6631 6930 1430 1280 1304 1429 3556 3726 649 581 591 648
57 6795 7138 1430 1280 1369 1514 3636 3826 649 581 621 687
HEAT EXCHANGER
FRAME, PASS
ENGLISH SI
Psig
Rigging Weight
(lb) (see Note 2)
Water Volume
(gal)
kPa
Rigging Weight
(kg) (see Note 2)
Water Volume
(L)
FRAME 3, 1 AND 3 PASS 150 730 84 1034 331 318
FRAME 3, 2 PASS 150 365 42 1034 166 159
FRAME 4, 1 AND 3 PASS 150 1888 109 1034 856 413
FRAME 4, 2 PASS 150 944 54 1034 428 204
FRAME 5, 1 AND 3 PASS 150 2445 122 1034 1109 462
FRAME 5, 2 PASS 150 1223 61 1034 555 231
FRAME 3, 1 AND 3 PASS 300 860 84 2068 390 318
FRAME 3, 2 PASS 300 430 42 2068 195 159
FRAME 4, 1 AND 3 PASS 300 2162 109 2068 981 413
FRAME 4, 2 PASS 300 1552 47 2068 704 178
FRAME 5, 1 AND 3 PASS 300 2655 122 2068 1204 462
FRAME 5, 2 PASS 300 1965 53 2068 891 201
