Compex Technologies WPE54 - Manual (Page 95)

Chapter 5 Further Configuration
94
Set up Port Forwarding – For Custom Server
Otherwise, in order to set up
Internet applications which are
not defined in the Known
Server section, go to Custom
Server:
Key in the Private IP Address.
Define the Port numbers to use.
Select the relevant Protocol from the drop down list.
Identify the Server Type.
Click on
Add button.
We entered a Private IP Address of 192.168.168.55, defined ports 15 to 89 as the
application Ports, selected UDP from the Protocol drop-down list and labelled the Server
Type as LAN Game.
The updated NAT Static Port Based Entries will reflect your new entry.
If you want to assign more servers in your LAN, click on the
Add button.
Delete a table entry
If you want to delete any of the
table entries:
Select the entry to delete.
Click on the
Delete button.
The table will be refreshed.
