25 Series Final Meter Drive
25P: Meter Drive (Front type)
No idlers on mount.
top chain passes over single idler on shank
be sure to reconnect idler spring
25P: Meter Drive (Mid type)
be sure to reconnect idler spring
top chain passes between 2 idlers at mount
top chain passes between 2 idlers at shank
25P: Meter Drive (Rear type)
be sure to reconnect idler spring
top chain passes between 2 idlers at mount
top chain passes between 2 idlers at shank
1
2
0
26136
19T
90P
12T
4
3
2
26137
19T
116
12T
0
1
2
2
3
4
4
3
2
26138
19T
144
12T
2
3
4
