10HD Series Meter Drive Chain
10HD: Meter Drive (Front type)
No idlers on mount.
top chain passes under single idler on shank
be sure to reconnect idler spring
10HD: Meter Drive (Mid type)
be sure to reconnect idler spring
top chain passes between 2 idlers at mount
top chain passes between 2 idlers at shank
10HD: Meter Drive (Rear type)
be sure to reconnect idler spring
top chain passes between 2 idlers at mount
top chain passes between 2 idlers at shank
