6/29/2006

148-057M

49

Monitor Operation

Area Total / Implement Width

The area is derived from the forward speed and the programmed
implement width and is accumulated to whichever total is selected
on the display – total 1 or total 2.

Area will only accumulate while the drill is in work, i.e. forward
speed is being registered.

The two separate area totals can be independently reset to zero.

Display Area Total

1.

Select the

channel.

2.

Press

to cycle between the two area totals.

The display will then show ‘tot.1’ or ‘tot.2’ before displaying the
area accumulated since that total was last reset.

Reset Totals

1.

Select the

channel.

2.

Press

to cycle between the two area totals.

3.

Hold

for 5 seconds to zero that total.

2

3

Display Area Total

Select Total 1 or Total 2

Reset Total
