V-300, V-300F
148-057M 6/29/2006
44
Channel 1 Forward Speed
Channel 2 Area Total 1 or 2
Channel 3 Current/Tramline Bout
Channel 4 Fertilizer Shaft RPM
Channel 5 Seed Shaft RPM
Channel 6 Seed/Fertilizer Hopper Level Low
1. Select the channel then
PRESS to switch between
Area Total 1 and 2.
OR:
2. Select the channel then
PRESS to manually
advance the Bout Number.
OR:
3. HOLD continuously to select the
programming mode. (Normal Mode
is resumed when the button is re-
leased).
The Control Switches
There are three active switches on the front panel used individually or in combination to program set/reset or se-
lect a function. The two small outer buttons have no function.
Current Speed
Channel/In-Out of
Work Indicator
Not Used
Program Key
Select
Channel
Not Used
PRESS to override auto-
matic advance of bout
number if drill is lifted,
(press again to resume)
OR:
HOLD to reset currently
displayed Area Total
