ClearOne XAP TH2 - Manual (Page 31)

27
Technical Services Group ~ 1-800-283-5936 (USA) ~ 1-801-974-3760
Set connector pinout
Pin Description Pin Description
1 To pin 6 of SET RJ-11C 4 Tip
2 To pin 5 of SET 5 To pin 2 of LINE
3 Ring 6 To pin 1 of LINE RJ-11C
Line connector pinout
Pin Description Pin Description
1 To pin 6 of LINE RJ-11C 4 Ring
2 To pin 5 of LINE 5 To pin 2 of SET
3 Tip 6 To pin 1 of SET RJ-11C
Appendices ~ Appendix B: Pinouts
RS-232 COM port pinout
Pin Description Pin Description
1 DCD 6 DSR
2 TXD 7 CTS
3 RXD 8 RTS
4 DTR 9 Not used
5 Ground
