Elr 7000 series multi point lock, 5 installation of inside escutcheon – SARGENT 7000 Series Vertical Rod Lock User Manual
Page 8
Copyright © 2013, Sargent Manufacturing Company
, an ASSA ABLOY Group company
. All rights reser
ved.
Reproductions in whole or in part without express written permission of Sargent Manufacturing Company is prohibited.
1/31/13
A8147A • 800-810-WIRE (9473) • www.sargentlock.com
8
ELR 7000 Series Multi Point Lock
1. Position escutcheon against door by hooking the top
edge on the top of the ELR assembly.
Verify that no wires are being pinched.
2. Mount inside escutcheon assembly to plate
using (1) #8-32 x 5/8" Phillips flat head
undercut machine screw, Figure 5B.
5 Installation of Inside Escutcheon
Fig. 5
Fig. 5B Machine
screw detail
