ELR 7000 Series Multi Point Lock
ITEM PART # Description Req.
1 MP-7XX-2 WD/MD/AD Inside Trim Assembly 1
2 7XX-2 Outside Trim Assembly 1
3A 94-2411 MD/AD Inner Chassis Assembly
94-2412 MD/AD Inner Chassis Assembly, Fire (12-)
94-2414 MD/AD Monitoring Inner Chassis, Fire (53-/12-53-)
3B MD69IT WD Inner Chassis Assembly 1
WD69IT WD Monitoring Inner Case (53-)
4 68-0888 Bottom Case 1
5A 68-7062 MD/AD Top Rod and Bolt Assembly 1
5B 68-5829 WD Top Rod and Bolt Assembly 1
6 68-5374 Top Case Assembly 1
7 96-2085 Bottom Rod and Bolt Assembly 1
8 97-0825 Standard Plate (Rectangular) (Not shown) 2
97-0826 Sculpted Plate (Optional) (Not shown)
9 68-1264 WD Top Case Bracket (Not shown) 1
10 97-4056 Cover Assembly 1
10B 650 Top Strike Pack (Not shown) 1
606 Bottom Strike Pack, Fire (12-)(HC)(WS) (Not shown)
652 Top and Bottom Strike Pack, STD (Not shown)
11 52-4697 ELR Assembly 1
11A 94-2415 MD/AD Screw Pack (Not shown) 1
11B 94-2431 WD Screw Pack (Not shown) 1
12 52-5236 Screw Pack (Not shown) 1
12A 52-4723 MD/AD Mounting Hardware 1
12B 52-4724 WD Mounting Hardware 1
How to Specify ET Trim
Specify: 7 for ET Series Trim, Function, Suffix, Lever, Finish and handing (e.g., 713-2 ETL
x 26D x RH).
Note: Suffix requirements are based on type of device to be used:
• -2 suffix is required for all 7000, WD, MD and AD.
• MP- prefix is for inside 7000 trim.
Parts Breakdown Continued...
