TRANSMIG 175i
INSTALLATION, OPERATION AND SETUP
3-20
Manual 0-5143
CAUTION
Remove any packaging material prior to use. Do not block the air vents at the front or rear of the
Welding Power Source.
A-09589_AB
Negative Welding
Terminal (-)
Positive Welding
Terminal (+)
Work Lead
Electrode
Holder
MIG Torch
polarity lead
not connected.
Figure 3-18: Setup for Manual Arc Welding.
