Tweco 400 Ultra-Cut XT Plasma Cutting System User Manual
Page 53
ULTRA-CUT 100 XT/200 XT/300 XT/400 XT
Manual 0-5297
INSTALLATION
3-25
Preparation
1. Remove the screws securing the Cover Panel to the Module.
Loosen or remove 2 screws
Remove 2 Screws
Art # A-09139_AC
Cover Removal
2. Carefully remove the cover from the module noting the attached wire harness that connects to J1. Remove
the wire harness and then set the cover to the side.
Art # A-09140
