ULTRA-CUT 100 XT/200 XT/300 XT/400 XT
�� PARTS LISTS Manual 0�5297
6.09 Power Supply Replacement Parts - Lower Right Side
Item # Qty Description Ref. Des. Catalog #
1 1 Coolant Tank Cap ��5124
2 1 Coolant Tank 9�730
3 1 Coolant level Sensor 9�7307
4 1 Pump, Coolant, Assembly 9�7309
5 1 Motor, Pump 9��1
1 Cooling Fan(s)
Single large for 300A / 400A systems 9�734�
Two smaller for 100A / 200A systems 9�7312
7 1 Radiator
300A / 400A systems 9�7349
100A / 200A systems 9�7311
� 1 Flow, Switch (Not shown) FS1 9�7310
9 1 Bubble (flow) Sensor (Not shown) FL1 9�9297
10 1 Current Transducer, 300A HCT1 W7005324
2
3
4
5
6
7
1
Art # A-11984
