SoundOff Signal Pinnacle LED - Manual (Page 14)

Page 14
LIGHT MODULE WIRE HARNESS LOCATIONS
CONTROLLER
& WIRE HARNESS INSTRUCTIONS
Colors shown indicate color coded labels on
wiring harness.
White is used for all Take Down lights. Replace
color indicated on diagram with white labeled
wire.
SM=Small connector used on Alley lights only.
If modules are being replaced in the field make
sure they are reinstalled with single wire
connectors to FRONT of vehicle. See below.
Green
Single Wire
Red, Blue Double
Wire (Rear)
BLUE
REPLACEMENT OF INBOARD, CORNER, TAKEDOWN AND ALLEY LED MODULES:
1. Disconnect main power.
2. Remove top cover by removing 6 sealed torx head screws.
3. Locate module and remove mounting screw. Pull module from lightbar.
4. Remove connector from rear of module by disengaging locking latch and pull
connector from back of module. (see illustration at right)
5. Push module connector into module ensuring locking latch is seated properly.
6. Replace module and 2 screws that fasten module to base extrusion.
7. Restore power to bar and test new module to ensure functionality.
8. Replace top cover of bar with screws removed in step 2.
DRIVER
SIDE
PASSENGER
SIDE
FRONT
36” BAR
C
D
A
E
B
E
11 12 13 14
31 32 33 34
ORANGE
SM
BROWN
GREEN RED RED GREEN
ORANGE
SM
BROWN
GREEN RED RED GREEN
42” BAR
C
D
A
E
B
E
11 12 13 14 15
31 32 33 34 35
ORANGE
SM
BROWN
BLUE GREEN RED GREEN
ORANGE
SM
BROWN
BLUE GREEN RED GREEN BLUE
48” BAR
C
D
A
E
B
E
11 12 13 14 15 16
31 32 33 34 35 36
ORANGE
SM
BROWN
ORANGE
SM
BROWN
BLUE GREEN RED RED GREEN
BLUE GREEN RED RED GREEN
BLUE
BLUE
54” BAR
C
D
A
E
B
E
11 12 13 14 15 16 17
31 32 33 34 35 36 37
YELLOW
ORANGE
SM
BROWN
ORANGE
SM
BROWN
BLUE GREEN RED GREEN BLUE
BLUE GREEN RED GREEN BLUE
YELLOW
YELLOW YELLOW
60” BAR
C
D
A
E
B
E
11 12 13 14 15 16 17 18
31 32 33 34 35 36 37 38
ORANGE
SM
BROWN
ORANGE
SM
BROWN
BLUE GREEN RED RED GREEN
BLUE GREEN RED RED GREEN
BLUE
BLUE
YELLOW
YELLOW
YELLOW
YELLOW
72” BAR
C
D
A
E
B
E
ORANGE
SM
BROWN
ORANGE
SM
BROWN
BLUE GREEN RED* RED GREEN
BLUE BLANK RED* RED* BLANK
BLUE
BLUE
YELLOW
YELLOW
YELLOW
YELLOW
31 32 33 34 35 36 37 38 39 40
11 12 13 14 15 16 17 18 19 20
RED* RED*
RED* RED*
* DENOTES
DOUBLE WIRE
UNITS IN FRONT
ON 72” BAR
ONLY!
