Dimensional data – Powers 596 Series Flowrite II Heavy Duty Control Valves - Type MI Mixing User Manual
Page 6

6
Table-4 Dimensions for 596MI Series Valves
Nominal Pipe Size
2-1/2"
3"
4"
5"
6"
A
8.500
9.500
11.500
13.000
14.000
STROKE
0.875
0.875
0.875
1.750
1.750
B
5.375
6.375
8.500
8.750
9.750
C
3.500
3.750
4.500
5.000
5.875
D
10.375
10.375
10.375
N/A
N/A
E
10.000
10.000
10.000
N/A
N/A
F
16.625
16.625
16.625
19.000
19.000
G
10.313
10.313
10.313
10.313
10.313
Valve Weight (lbs)
62.00
82.00
115.00
180.00
264.00
Weight w/46"
75.00
95.00
128.00
N/A
N/A
Weight w/100"
87.00
107.00
140.00
205.00
289.00
Dimensional Data
n
G
F
B
C
100" Actuator
E
D
A
46" Actuator
2-1/2" to 6" Valve Bodies
Figure 6
E
D
C
A
B
Figure 7
Table - 5 Flange Detail for American Standard 125 lb. Cast Iron Pipe Flanges
Flanges
Drilling
Bolting
Length of
Valve
Flange
Flange
Diameter of
Diameter of
Number
Diameter
Machine
Size
Diameter
Thickness
Bolt Circle
Bolt Holes
of Bolts
of Bolts
Bolts
A
B
C
D
E
2-1/2"
7"
11/16"
5-1/2"
3/4"
4
5/8"
2-1/2"
3"
7-1/2"
3/4"
6"
3/4"
4
5/8"
2-1/2"
4"
9"
15/16"
7-1/2"
3/4"
8
5/8"
3"
5"
10"
15/16"
8-1/2"
7/8"
8
3/4"
3"
6"
11"
1"
9-1/2"
7/8"
8
3/4"
3-1/4"
