In systems where the IMT card is not fitted inside the PC, it is powered
by an external power supply. This power supply is connected to J12.
This appears as an 8-pin connector on Issue 1 cards, and a 3-pin
connector on Issue 2 cards.
If you need further information about powering the IMT card from an
external power supply please contact your supplier.
A6 Composite Video Features Connector - J10
The Composite Video Features connector allows additional 4 composite
video ports to be added to your PC. To find out more about this product
contact your supplier.
Do not attach anything to any of the pins on J10.
A6 Other Jumpers
J1 and J5
J1 is the debug port. It supplies serial debugging information. Do not
attach anything to any of its pins.
J5 is the flash reset port. Do not attach anything to any of its pins.
