WINCUEPRO FOR AVSTAR USER GUIDE
APPENDIX D
VERSION 1.30
111
QTV 2001
Appendix E Wiring
E1
WinCue Multibutton Hand Control
E1.1 WinCue IMT card 9 way d connections
1 0v
2 0v
3 gnd
4 +5
5 +5
6 pot
7 n/c
8 marker
9 fwd/rev
pot = 10k
E1.2 9 way d Serial port connections
2……..rd……..
brown
4……..dtr……..
y
y
y
e
e
e
l
l
l
l
l
l
o
o
o
w
w
w
5……..gnd……..
w
w
wh
h
hi
i
it
t
te
e
e
7……..rts……..
purple
dtr and rts are used to generate the supply voltage
E1.3 P4 Multibutton Remote Connector 15 Pin D Male
9……..+ 5v……..
Red
10……..0v……..Black
11……..Pot……..
Green
12……..Fwd/Rev……..
Blue
500k pot for Foot control
E2
2 button Serial Hand Control
E2.1 9 way d Serial port connections
2……..rd……..
Red
4……..dtr……..
Blue
5……..gnd……..
Green
7……..rts……..
Y
Y
Y
e
e
e
l
l
l
l
l
l
o
o
o
w
w
w
dtr and rts are used to generate the supply voltage
