WINCUEPRO FOR AVSTAR USER GUIDE INSTALLATION OF WINCUEPRO NEWS
VERSION 1.30 9  QTV 2001
laptop
VL bus or PCI bus graphics card (PCI preferred)
800x600 16 color VGA display (1024x768 is recommended)
1.2 Before Installing Your Chosen Operating System
Before you install your chosen operating system you should configure your SCSI
card in accordance with the documentation supplied with it. DO NOT at this
stage install any hardware supplied with WinCuePro News.
1.3 The WinCuePro News Package
The WinCuePro News package consists of:
Laptop users will receive an IMT
box, not the IMT scroll card
Software (1 CD + license)
IMT Scroll Card
Scroll Controller
User-manual
1.4 IMT Scroll Card
The IMT scroll card allows WinCuePro News to prompt text in any language.
Data from the scroll card is sent to the prompter screen via the on-board
composite video channel. The IMT card also features an on-board genlock port.
In addition, an IMT scroll control can be attached to the IMT card leaving all the
ports on your PC free for other peripherals.
1.5 Installing the Hardware - Desktop PCs
Before installing the WinCuePro News software you have to install the IMT scroll
card. Your PC must be turned off before the IMT scroll card can be installed.
The IMT card will have been configured prior to shipment for the settings
required in your country. Therefore changes to jumpers or dipswitch settings
should not be necessary.
Refer to Appendix C for wiring diagrams.
Installing the IMT Card Inside a PC
1. Remove the cover from the PC’s case
2. The IMT card is configured it should be connected to the end of the SCSI cable.
