WINCUEPRO FOR AVSTAR USER GUIDE
APPENDIX A
VERSION 1.30
94
QTV 2001
A4 SCSI ID - SW2
By default, SCSI ID is set to 3. It can be changed using dipswitches 1,2
and 3 on SW2.
When a dipswitch is in the top position it is on. When it is in the bottom
position it is off. The dipswitch positions for each SCSI ID is shown in the
table below:
Dip
Switches
SCSI ID
1
2
3
0 On
On
On
1 On
On
Off
2 On
Off
On
3 On
Off
Off
4 Off
On
On
5 Off
On
Off
6 Off
Off
On
7 Off
Off
Off
A4 SCSI/Parallel Select - SW2
The IMT card can prompt using data sent through either the SCSI port
or parallel port of your PC. By Default it is set up to use SCSI. Dip
switches 4 on SW2 controls whether the SCSI or parallel port is used.
