WINCUEPRO FOR AVSTAR USER GUIDE APPENDIX A
VERSION 1.30 95  QTV 2001
When a dipswitch is in the top position it is on. When it is in the bottom
position it is off. The dipswitch positions for SCSI/parallel port selection
is shown in the table below:
Dip Switch
Port 4
SCSI Off
Parallel On
A5 Video (PAL or NTSC) - J11
The IMT card can produce either a PAL or NTSC composite video
signal. The signal available from the composite video port will have been
set at the factory, prior to dispatch. The signal type can be changed by
setting a jumper on J11 (Card Issue 1) or with switch 3 (Card Issue 2).
Issue 1 Issue 2
To enable NTSC place a jumper on leftmost
pins of J11, or turn Switch 1 on.
To enable PAL remove the jumper on
leftmost pins of J11, or turn Switch 1 off.
