Rockwell Automation Publication PFLEX-IN020C-EN-P - July 2013 9
PowerFlex 700S and 700H Frames 10...14 IP00, NEMA/UL Open Power Structures
Enclosure Requirements The following enclosure specifications must be met for proper installation.
Table 6 - Frames 10…12
Table 7 - Frame 13
Table 8 - Frame 14
Specification Frame 10 Frame 11 Frame 12
Width 600 mm (23.6 in.) Minimum 800 mm (31.5 in.) Minimum 1200 mm (47.2 in.) Minimum
Depth Minimum 600 mm (23.6 in.) or a minimum of 490 mm (19.3 in.) if the control frame is
installed in a position other than the front of the power structure.
Height Minimum 1800 mm (70.9 in.) if the AC choke is installed beneath the power structure,
otherwise a minimum of 1500 mm (59.1 in.).
Weight Enclosure must be able to support the total equipment weight stated if the power structure
and AC choke are installed in the same enclosure. Refer to the PowerFlex 700H and 700S AC
Drive, Frames 9…14 Installation Instructions, publication
PFLEX-IN006 , for component
weights.
Construction According to EN60439-1
Ventilation See Airflow and Ventilation Requirements on page 13 .
Specification Frame 13 (1)
(1) Refer to Frame 13 and 14 Component/Enclosure Configurations on page 11 for more information.
2 NFE Converters 3 NFE Converters DC Input
Width Enclosure A:
600 mm (23.6 in.) min
Enclosure B:
800 mm (31.5 in.) min Enclosures A and B:
800 mm (31.5 in.) min Enclosure A:
800 mm (31.5 in.) min
Depth Minimum 600 mm (23.6 in.) is required to accommodate the depth of the inverter units.
Height 2200 mm (86.6 in.)
Weight Enclosure must be able to support the total equipment weight stated if the power structure and AC
choke are installed in the same enclosure. Refer to the PowerFlex 700H and 700S AC Drive, Frames
9…14 Installation Instructions, publication
PFLEX-IN006 , for component weights.
Construction According to EN60439-1
Ventilation See Airflow and Ventilation Requirements on page 13 .
Specification Frame 14 (1)
(1) Refer to Frame 13 and 14 Component/Enclosure Configurations on page 11 for more information.
3 NFE Converters 4 NFE Converters 6 NFE Converters DC Input
Width Enclosures A, B and C:
800 mm (31.5 in.) Min. Enclosures A and D:
600 mm (23.6 in.) Min.
Enclosure B and C:
800 mm (31.5 in.) Min. Enclosures A, B, C, and D:
800 mm (31.5 in.) Min. Enclosures A and B:
800 mm (31.5 in.) Min.
Depth Minimum 600 mm (23.6 in.) is required to accommodate the depth of the inverter units.
Height 2200 mm (86.6 in.)
Weight Enclosure must be able to support the total equipment weight stated if the power structure and AC
choke are installed in the same enclosure. Refer to the PowerFlex 700H and 700S AC Drive, Frames
9…14 Installation Instructions, publication
PFLEX-IN006 , for component weights.
Construction According to EN60439-1
Ventilation See Airflow and Ventilation Requirements on page 13 .
