Rockwell Automation 20D PowerFlex 700S/700H Frames 10...14 IP00, NEMA/UL Open Power Structures User Manual
Page 39
Rockwell Automation Publication PFLEX-IN020C-EN-P - July 2013
39
PowerFlex 700S and 700H Frames 10...14 IP00, NEMA/UL Open Power Structures
Figure 24 - PowerFlex 700H Star Coupler Board Termination Points (Frames 12 and 14)
4. Secure the cable bundle using cable ties as necessary to guard against cable
damage.
5. For Frames 10…12, replace the protective covers on the drive and continue
with Output Power Wiring on page
49
. For Frames 13 and 14, continue
with Frames 13 and 14 NFE Converter to Inverter Connections on page
47
.
H8
H7
H6
H5
H4
H3
H2
H1
H18
H17
H16
H15
H14
H13
H12
H11
H23
H22
H21
X2
Fiber Optic
Connectors
Fiber Optic
Connectors
