PowerFlex 700S and 700H Frames 10...14 IP00, NEMA/UL Open Power Structures
Power Structure Weights and Lifting Instructions
Use the weights listed in the tables below and the Lifting Instructions on page
8
when lifting the power structures.
Table 3 - Frames 10…12 Approximate Weights
ATTENTION: To guard against possible personal injury and/or equipment
damage...
• Remove any wiring access covers at the top of the drive.
• Do Not allow any part of the drive or lifting mechanism to make contact with
electrically charged conductors or components.
• At no time should a person or their limbs be directly underneath the items
being lifted.
• Do not subject the load to high rates of acceleration or deceleration.
• Inspect all lifting hardware for proper attachment before lifting drive unit.
Frame
Size
Drive
Voltage
Class
Drive
Rated
Amps
Power Structure Weight
AC Choke Weight
AC Input Drive and
Packaging Weight
(4)
(4) DC input drive and packaging weight is equal to the weight of the power structure(s).
kg (lb)
kg (lb)
kg (lb)
10
400
385
120 (265)
115 (254)
235 (519)
460
120 (265)
115 (254)
235 (519)
500
120 (265)
115 (254)
235 (519)
600
261
120 (265)
53 (117)
173 (382)
325
120 (265)
84 (185)
204 (450)
385
120 (265)
84 (185)
204 (450)
416
120 (265)
84 (185)
204 (450)
11
400
590
210 (463)
84 (185)
(2)
(2) Two AC chokes are required for this frame 11 AC drive.
378 (833)
650
210 (463)
84 (185)
(2)
378 (833)
730
210 (463)
84 (185)
(2)
378 (833)
600
460
210 (463)
115 (254)
325 (717)
502
210 (463)
115 (254)
325 (717)
590
210 (463)
115 (254)
(2)
440 (970)
12
400
820
120 (265)
(1)
(1) Two power structures are required per frame 12 drive.
115 (254)
(3)
(3) Two AC chokes are required per frame 12 AC drive.
350 (772)
920
120 (265)
(1)
115 (254)
(3)
350 (772)
1030
120 (265)
(1)
115 (254)
(3)
350 (772)
600
650
120 (265)
(1)
84 (185)
(3)
288 (635)
750
120 (265)
(1)
84 (185)
(3)
288 (635)
820
120 (265)
(1)
84 (185)
(3)
288 (635)
